Editor

The editorConfig section defines the editor interface parameters.

type: object

The data received from the document editing service using the onMakeActionLink event or the onRequestSendNotify event in data.actionLink parameter, which contains the information about the action in the document that will be scrolled to.

Example:

{
  action: {
    type: "bookmark",
    data: "bookmark_name",
  },
}

actionLink.action​

type: object

The action object that defines what to scroll to in the document.

actionLink.action.type​

type: "bookmark" | "comment"

The type of action in the document.

Example: "bookmark"

actionLink.action.data​

type: string

The data associated with the action: the bookmark name or the comment ID.

Example: "bookmark_name"

callbackUrl​

type: string | required

The absolute URL to the document storage service. This service must be implemented by the software integrators who use ONLYOFFICE Docs on their own server.

Example: "https://example.com/url-to-callback"

coEditing​

type: object

The co-editing mode and the possibility to change it. This parameter is used to apply the co-editing and viewing modes.

Example:

{
  "mode": "fast",
  "change": true
}

coEditing.mode​

type: "fast" | "strict" | default: "fast"

The co-editing mode.

note

In case mode setting is changed in the editor interface, it will be stored in the browser local storage and will overwrite any values sent as the editorConfig.coEditing.mode parameter. The fast mode requires autosave to be enabled, so customization.autosave will be forced to true if it is set to false.

Example: "fast"

coEditing.change​

type: boolean | default: true

Whether to allow changing the co-editing mode in the editor interface.

Example: true

Coediting modeCoediting mode

createUrl​

type: string

The absolute URL of the document where it will be created and available after creation.

note

If not specified, the Create button will not be displayed. Instead of this parameter, you can use the onRequestCreateNew event.

Example: "https://example.com/url-to-create-document"

Create URLCreate URL

fileChoiceUrl​

type: string

The URL of the file selection dialog opened in an iframe for inserting images, selecting documents for comparison, or choosing mail merge data sources. The URL can contain the {documentType} and {fileExt} placeholders, which will be replaced with the appropriate values (e.g., ImagesOnly, DocumentsOnly).

note

The {documentType} placeholder is required for the Image from Storage and Document from Storage buttons to appear.

Deprecated

Instead of this parameter, use the onRequestInsertImage, onRequestSelectDocument, or onRequestSelectSpreadsheet events.

Example: "https://example.com/filechoice?type={documentType}"

lang​

type: string | default: "en"

The editor interface language. Uses two-letter (de, ru, it, etc.) language codes.

note

To translate the editor interface into Portuguese (Portugal) or Chinese (Traditional, Taiwan) (added in version 7.2), use the four-letter language codes pt-PT or zh-TW, respectively. The two-letter pt language code sets Portuguese (Brazil) and the zh code specifies Chinese (People's Republic of China).

Supported language codes
CodeLanguage
arArabic
azAzerbaijani
beBelarusian
bgBulgarian
caCatalan
csCzech
daDanish
deGerman
elGreek
enEnglish
esSpanish
euBasque
fiFinnish
frFrench
glGalician
heHebrew
hrCroatian
huHungarian
hyArmenian
idIndonesian
itItalian
jaJapanese
koKorean
loLao
lvLatvian
msMalay
nlDutch
noNorwegian
plPolish
ptPortuguese (Brazil)
pt-PTPortuguese (Portugal)
roRomanian
ruRussian
siSinhala
skSlovak
slSlovenian
sqAlbanian
srSerbian (Latin)
sr-CyrlSerbian (Cyrillic)
svSwedish
trTurkish
ukUkrainian
urUrdu
viVietnamese
zhChinese (Simplified)
zh-TWChinese (Traditional)

Example: "en"

location​

type: string | default: ""

The default measurement units. Specify us or ca to set inches.

Deprecated

Starting from version 8.2, please use the region parameter instead.

Example: "us"

mode​

type: "edit" | "view" | default: "edit"

The editor opening mode.

Example: "view"

mergeFolderUrl​

type: string

The absolute URL to the folder for saving the mail merge result.

Deprecated

Instead of this parameter, use the onRequestSaveAs event.

Example: "https://example.com/url-to-merge-folder"

recent​

type: object[]

The presence or absence of the documents in the Open Recent... menu option.

Example:

[
  {
    "folder": "Example Files",
    "title": "exampledocument1.docx",
    "url": "https://example.com/exampledocument1.docx"
  }
]

recent.folder​

type: string

The folder where the document is stored. Can be empty if the document is in the root folder.

Example: "Example Files"

recent.title​

type: string

The document title that will be displayed in the Open Recent... menu option.

Example: "exampledocument1.docx"

recent.url​

type: string

The absolute URL to the document where it is stored.

Example: "https://example.com/exampledocument1.docx"

Recent documentsRecent documents

region​

type: string | default: "en-US"

The default display format for currency, date, and time (in the Spreadsheet Editor only). Is set using the four-letter (en-US, fr-FR, etc.) language codes.

note

If lang is defined and a matching regional setting exists, the default value is taken from the lang parameter. Otherwise, en-US is used.

info

Starting from version 8.2, this parameter also defines the default measurement units in all editor types. For the ...-US or ...-CA regions, inches are used by default if other values are not specified in the editorConfig.customization.unit parameter.

Supported regional settings
CodeRegion
ar-EGArabic (Egypt)
ar-SAArabic (Saudi Arabia)
az-Latn-AZAzerbaijani (Latin, Azerbaijan)
bg-BGBulgarian (Bulgaria)
cs-CZCzech (Czech Republic)
da-DKDanish (Denmark)
de-ATGerman (Austria)
de-CHGerman (Switzerland)
de-DEGerman (Germany)
el-GRGreek (Greece)
en-AUEnglish (Australia)
en-GBEnglish (United Kingdom)
en-IDEnglish (Indonesia)
en-USEnglish (United States)
es-ESSpanish (Spain)
es-MXSpanish (Mexico)
fi-FIFinnish (Finland)
fr-CHFrench (Switzerland)
fr-FRFrench (France)
hu-HUHungarian (Hungary)
id-IDIndonesian (Indonesia)
it-CHItalian (Switzerland)
it-ITItalian (Italy)
ja-JPJapanese (Japan)
ko-KRKorean (Korea)
lv-LVLatvian (Latvia)
nl-NLDutch (Netherlands)
pl-PLPolish (Poland)
pt-BRPortuguese (Brazil)
pt-PTPortuguese (Portugal)
ru-RURussian (Russia)
sk-SKSlovak (Slovakia)
sl-SISlovenian (Slovenia)
sr-Cyrl-RSSerbian (Cyrillic, Serbia)
sr-Latn-RSSerbian (Latin, Serbia)
sv-FISwedish (Finland)
sv-SESwedish (Sweden)
tr-TRTurkish (Turkey)
uk-UAUkrainian (Ukraine)
vi-VNVietnamese (Vietnam)
zh-CNChinese (Simplified)
zh-TWChinese (Traditional)

Example: "en-US"

saveAsUrl​

type: string

The absolute URL to the folder for saving files.

Deprecated

Instead of this parameter, use the onRequestSaveAs event.

Example: "https://example.com/url-to-save-folder"

sharingSettingsUrl​

type: string

The absolute URL to the document sharing settings page.

Deprecated

Instead of this parameter, use the onRequestSharingSettings event.

Example: "https://example.com/url-to-sharing-settings"

templates​

type: object[]

The presence or absence of the templates in the Create New... menu option.

Example:

[
  {
    "image": "https://example.com/exampletemplate1.png",
    "title": "exampletemplate1.docx",
    "url": "https://example.com/url-to-create-template1"
  }
]

templates.image​

type: string

The absolute URL to the image for the template.

Example: "https://example.com/exampletemplate1.png"

templates.title​

type: string

The template title that will be displayed in the Create New... menu option.

Example: "exampletemplate1.docx"

templates.url​

type: string

The absolute URL to the document where it will be created and available after creation.

Example: "https://example.com/url-to-create-template1"

TemplatesTemplates

user​

type: object

The user currently viewing or editing the document.

note


If you are subscribed to the onRequestUsers event and send an avatar via the setUsers method, the user.image field in the initialization config is not required. It is not recommended to specify this parameter if the avatar is in base64 format and the initialization config is signed with JWT, since the token will become too long.

Example:

{
  "group": "Group1,Group2",
  "id": "78e1e841",
  "image": "https://example.com/url-to-user-avatar.png",
  "name": "John Smith",
  "roles": ["Role1"]
}

user.group​

type: string

The group (or several groups separated with commas) the user belongs to. Can be used for customization.reviewPermissions, permissions.reviewGroups, or permissions.commentGroups.

Example: "Group1,Group2"

user.id​

type: string

The identification of the user. The length is limited to 128 symbols. This information is stored and used to:

  • distinguish co-authors,
  • indicate the author of the last changes when saving and highlighting history (in the list of changes),
  • count users with access for a license based on the number of users.
note

It is recommended to use a unique anonymized hash. Do not use sensitive data such as real name or email.

Example: "78e1e841"

user.image​

type: string

The path to the user's avatar.

Example: "https://example.com/url-to-user-avatar.png"

user.name​

type: string

The full name of the user. The length is limited to 128 symbols.

Example: "John Smith"

user.roles​

type: string[]

The roles assigned to the user for PDF form filling. The first role in the array is used to determine which form fields the user can fill.

Example: ["Role1"]

customization​

type: object

The customization section defines the editor customization parameters: standard branding and white label.

embedded​

type: object

The embedded section defines the embedded mode parameters.

plugins​

type: object

The plugins section defines the runtime plugin parameters.

wopi​

type: object

The WOPI configuration section. Used only when the editor is integrated via WOPI.

wopi.FileNameMaxLength​

type: integer | default: 250

The maximum length for file names that the WOPI host supports, excluding the file extension. Corresponds to the FileNameMaxLength property from CheckFileInfo.

Example: 20

Example​

const config = {
  // ...
  editorConfig: {
    actionLink: {
      action: {
        type: "bookmark",
        data: "bookmark_name",
      },
    },
    callbackUrl: "https://example.com/url-to-callback",
    coEditing: {
      mode: "fast",
      change: true,
    },
    createUrl: "https://example.com/url-to-create-document",
    lang: "en",
    mode: "edit",
    recent: [
      {
        folder: "Example Files",
        title: "exampledocument1.docx",
        url: "https://example.com/exampledocument1.docx",
      },
    ],
    region: "en-US",
    templates: [
      {
        image: "https://example.com/exampletemplate1.png",
        title: "exampletemplate1.docx",
        url: "https://example.com/url-to-create-template1",
      },
    ],
    user: {
      group: "Group1,Group2",
      id: "78e1e841",
      image: "https://example.com/url-to-user-avatar.png",
      name: "John Smith",
    },
    customization: {
      // ...
    },
    embedded: {
      // ...
    },
    plugins: {
      // ...
    },
  },
};

const docEditor = new DocsAPI.DocEditor("placeholder", config);

The example.com is the name of the server where document manager and document storage service are installed. See the How it works section to find out more on ONLYOFFICE Docs service client-server interactions.
